Bridge Automatic 1x1 Fence Mesh Welding Machine

Name: Bridge Automatic 1x1 Fence Mesh Welding Machine
Brand: Huayang
Price: 1 USD

Brand Name : Huayang

Model Number : R-DHW

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : T/T

Supply Ability : 20 sets/month

Delivery Time : 30 days

Packaging Details : 1.Machine will be covered with plastic film and fastened by steel wire in container. 2. Spare parts will be packed into carton box and fastened stable in container.

Product name : Bridge Using Automatic Fence Mesh Welding Machine

Trademark : Huayang

Electrodes : Single or double row

Mechanical Specifications : According to Customer Requirement

Pressure way : Spring-weighted

Mesh Type : Rolling Mesh

Control System : PLC

Welding way : Silicon controlled synchronous control

Application : Building&Construction

Suitable wire to the machine : Low carbon steel wire

Contact Now

Bridge Using Automatic Fence Mesh Welding Machine

1. Product description

Bridge Using Automatic Fence Mesh Welding Machine is used for making wire mesh. The main body frame using thick steel plate and steel, that make the main structure is more fastness,and compact. The weft feeding system, the stepper motor automatically droping the weft automatic, it make the placed more accurately. Pulling mesh system adopts servo motor to pull the network, making the size of the pulling mesh more standard and accurate,and can adjust the cross wire distance at any size.

2. Technical parameter

Model	Mesh width	Minimum mesh size (inch)	Wire diameter(mm)	Welding speed (rows/min)	Roll mesh length (m)	Other available mesh size (inch)
R- DHW	6 feet	1/2x1/2	0.45-0.85	90-120	130	1/2x1, 1x1/2, 1x1, 2x2
R- DHW	6 feet	1/2x1/2	0.6-1.3	90-120	110	1/2x1, 1x1/2, 1x1, 2x2
R- DHW	6 feet	1/2x1/2	0.8-1.6	80-90	100	1/2x1, 1x1/2, 1x1, 2x2
R- DHW	6 feet	1x1	0.45-0.85	90-120	130	1x2, 2x1, 2x2, 2x4
R- DHW	6 feet	1x1	0.6-1.3	90-110	110	1x2, 2x1, 2x2, 2x4
R- DHW	6 feet	1x1	0.8-1.6	90-110	100	1x2, 2x1, 2x2, 2x4
R- DHW	6 feet	1x1	1.4-2.6	80-90	80	1x2, 2x1, 2x2, 2x4

3. Application area

Bridge Using Automatic Fence Mesh Welding Machine is common uses for welded wire mesh, or steel mesh include: fencing panels, wire partitions, wire container panels, wire baskets, animal cages, enclosure works, screens, security panels, shelving, signage, stairways/treads, fishing traps and concrete reinforcement.

4. Advantages

a. This machine adopts PLC control technique, both separate-phases welding and welding time composed of digital and integrated electric circuit, more intelligent and rational, once pressing, and separate welding.

b. The welding head is made of chromium-zirconium copper, with good electrical conductivity, hard material and abrasion resistance.

c. High stability ,low noise, automatically straightening, automatically feeding wire .
